VISU-PRO-AL-100 Series
- High quality aluminum housing
- Display sizes from 10.1″ to 21.5″
- Modern, slim design with aluminum frame
- PCT-glass-multi-touch with scratch-resistant surface
- Front protected to IP65 (optional all side IP65 protection)
- 9 ~ 36V DC voltage input
- VGA, DVI and HDMI support
- VESA mounting and optional table top stand
- Suitable for 24 x 7 use
- Optional integrated speakers
The Industrial Displays of the VISU-PRO-AL-100 series represent a perfect compromise between performance, energy consumption and price.
The display variants 10.1″ – 21.5″ are ideally suited to master almost all tasks in the field of control and visualization without any problems, yet are nevertheless very economical in terms of power consumption and heat dissipation.
The VGA, DVI and HDMI interfaces are available for connection to an industrial PC.
The robust aluminium housing not only impresses with its low construction depth, but also cools and reliably protects the high-quality industrial components of the touch monitor. A capacitive touchscreen is available for operating the industrial displays. The touchscreen is flush-mounted, installed without dirt edge to the display, extremely precise and absolutely suitable for industrial use.
1 x power input, 1 x VGA, 1 x DVI, 1 x HDMI, 1 x USB (Touchscreen)
12 ~ 24V DC, optional 100 - 240V AC integrated power supply
0°C ~ 40°C, 10 - 90% no condensing at 40°C
10.1" 1280 x 800 px 350 cd/m²
12" 800 x 600 px 250 cd/m²
12" XGA 1024 x 768 px 500 cd/m²
15" 1024 x 768 px 300 cd/m²
15.6" HD 1920 x 1080 px 220 cd/m²
17" 1280 x 1024 px 250 cd/m²
18.5" 1366 x 768 px 200 cd/m²
19" 1280 x 1024 px 250 cd/m²
21.5" 1920 x 1080 px 250 cd/m²
10.1" 800:1 16.7M
12" 700:1 16.7M
12" XGA 700:1 16.7M
15" 700:1 16.7M
15.6" HD 500:1 16.7M
17" 1000:1 16.7M
18.5" 600:1 16.7M
19" 1000:1 16.7M
21.5" 1000:1 16.7M
10.1" 170/170
12" 160/160
12" XGA 160/160
15" 160/160
15.6" HD 170/160
17" 160/160
18.5" 170/160
19" 160/160
21.5" 160/160
10.1" 30.000
12" 50.000
12" XGA 50.000
15" 35.000
15.6" HD 35.000
17" 30.000
18.5" 30.000
19" 50.000
21.5" 30.000
10.1" 266 x 184 x 50 mm
12" on request
12" XGA on request
15" 361 x 285 x 50 mm
15.6" HD 403 x 248 x 56 mm
17" 395 x 330 x 56 mm
18.5" 462 x 287 x 56 mm
19" 427 x 352 x 56 mm
21.5" 529 x 327 x 56 mm
PCT glas-multi-touch, 7H surface hardness, lifetime >35.000.000 touches
Windows 7, Windows embedded Standard 7, Windows 8.x, Windows 10, Windows 10 IoT, Linux/Unix
